Thermal imaging monocular ThermTec Cyclone 315

Cyclone 315 is a compact and lightweight handheld thermal imaging monocular for short and medium-range observations. Features a NETD <20mK detector that delivers excellent image quality. AI self-learning algorithms that provide increasingly stable target image quality. With advanced features such as multi-target ranging, 20-hour battery life, 3-second fast startup, etc., it is an excellent entry-level choice to explore the world of thermal imaging. Determining the distance to your target is essential for success. When multiple targets come into view, the Cyclone employs AI technology to automatically measure the distance to each heat source, greatly enhancing observation efficiency.

With its 255g compact size and ergonomically curved design, the device fits perfectly in your hand, enabling full control with one hand and effortless access to all buttons, regardless of whether you are left-handed or right-handed. The carefully arranged button layout allows for immediate usability once you take hold of it.

Features:

• 384*288 thermal resolution, NETD less than 20mK;
• Excellent handheld ergonomic design for a perfect operating experience;
• Silent button with no noise;
• Various colour palettes for customizable use;
• Advanced AI algorithm suitable for diverse distance measurements simultaneously;
• Incomparably simple UI interface;
• Up to 32GB storage capacity;
• 1024*768 resolution with a 0.39-inch OLED display;
• Three types of digital zoom available;
• Fast boot within 3 seconds;
• Replaceable lithium batteries provide up to 20 hours of continuous work;
• A variety of imaging modes including forest, target, and outline.

Specifications:

• Resolution: 384x288;
• Pixels: 12 µm;
• NETD: 20mK;
• Spectral range: 8-14 µm;
• Frame rate: 50HZ;
• Detection distance: 750 m;
• Lens: 15 mm;
• Field of view: 17.5° x 13.1°;
• Magnification: 1.4x;
• Digital zoom: 1x, 2x, 4x;
• Type: AMOLED;
• Resolution: 1024x768;
• Screen size: 0.39 inches;
• USB connection: Type-C
• Integrated memory: 32 GB;
• Battery operating time: 10 h;
• Operating temperature: -20°C - +50°C;
• Protection level: IP67;
• Weight: 255 g;
• Size: 139 x 76 x 54 mm.
